ARLU Neo S5 Invisible/Concealed Hinge up to 132lbs

The Argenta Invisible neo is a 3D-adjustable concealed hinge with concealed screws and a high-quality look and feel. In addition, these hinges come with our Easy-Hook system, meaning doors can be placed by just one person working alone. Invisible neo is reversible and can be used for both left and right-hand doors. What makes invisible neo so unique? Ease of use Easy-Hook: installation and 3D adjustment can be performed by just one person working alone Universal: invisible neo is suitable for both left and right-hand doors 3D-adjustable: these invisible hinges can be set in height, width and depth Opening angle: these invisible hinges have an opening angle of 180°   Durability and Safety Fire-resistant: when combined with an intumescent kit, invisible neo S5 is fire-resistant for 30 minutes.   Aesthetics Available colors: Invisible Neo S5 is available in 4 colors Detail: no visible adjustment and fastening screws due to cover plates Sizes: invisible neo is available in three sizes with different load-bearing capacities: S5, M6 and L7   Weight Table Number of Hinges 2 Hinges 3 Hinges Max door weight according to door width 28.74 inches 165lbs 209lbs 32.68 inches 154lbs 198lbs 36.61 inches 143lbs 187lbs 40.55 inches 132lbs 176lbs For easier installation, please see our ARLU Invisible Hinge Milling Template
